铧式犁系列：Share Plow
铧式犁是与四轮拖拉机配套的全悬挂式铧犁，主要适用于沙壤土地和熟地旱田的耕翻作业。该系列铧式犁具有调节简单、耕作适应范围广、作业质量好、耕后地表平整的特点。
1Lseries share plow is a four-wheeltractor mounted plow, mainly used for plowing loam, the sand loam , cultivatedand dry land.
Advantages:
This tractor farm plow hasgood efficiency
The mouldboard plow is insimple adjustment
Wide scope of application
The width of plow sharecould be 20cm,25cm,30cm,35cm.
Material of plough tip is65Mn steel
Working depth could be adjusted
型号 Model | 单位 | 1L-220 | 1L-320 | 1L-420 | 1L-520 | 1L-225 | 1L-325 | 1L-425 | 1L-525 |
工作幅宽 Working width | mm | 400 | 600 | 800 | 1000 | 500 | 750 | 1000 | 1250 |
工作深度 Working depth | mm | 200~250 | |||||||
犁体数量 Number of bottoms | 2 | 3 | 4 | 5 | 2 | 3 | 4 | 5 | |
整机重量 Total weight | kg | 64 | 100 | 130 | 170 | 125 | 170 | 240 | 270 |
配套动力 Matched power | hp | 15~25 | 25~35 | 35~45 | 50~60 | 25 | 40 | 50 | 65 |
挂接方式 linkage | I类三点悬挂 Three-point I suspension type | II类三点悬挂Three-point suspension II type | I类三点悬挂Three-point suspension I type | II类三点悬挂 Three-point suspension II type | |||||
选装配置The items selectable | |||||||||
